고벨코 유성 기어 SK135 변동 감축 YX32W00002S102 회전 모터 손잡이 부품
무료 샘플과 쿠폰을 받으려면 연락하세요.
왓츠앱:0086 18588475571
웨이 채팅: 0086 18588475571
스카이프: sales10@aixton.com
걱정이 있으시면 24시간 온라인 서비스를 제공합니다.
x제품 상세 정보
| 기계모델 | SK135SRLC SK115SRDZ-1E ED150-1E SK115SRDZ-1E | 부품번호 | YX32W00002S102 |
|---|---|---|---|
| 이름 | 로터리 모터 샤프트 | 애플리케이션 | 무한궤도 굴착기 |
| 품질 | 애프터 매트 | 보증 | 3개월 |
| 강조하다 | SK135 유성 기어 부분,YX32W00002S102 유성 기어 부분,SK115SRDZ-1E 회전식 모터축 |
||
제품 설명
Kobelco Planetary Gear Parts SK135 Swing Reduction YX32W00002S102 Rotary Motor Shaft
Description
|
Brand: |
Belparts
|
|
Name: |
Rotary Motor Shaft
|
|
Model: |
SK135SRLC SK115SRDZ-1E ED150-1E SK115SRDZ-1E
|
|
Part number
|
YX32W00002S102 |
|
Delivery: |
By sea,by air,by express
|
|
After-sales service provided: |
Online support
|
|
Hight light: |
kobelco
|
|
Warranty: |
3 months
|
Drawing of the pump
List of spare parts
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| . . | YX32W00002F1 | [1] | MOTO-REDUCTION GEAR | KOB ASSY (SWING) Superseded by part number: YX32W00002F2 |
| . . | YX32W00002F2 | [1] | MOTO-REDUCTION GEAR | KOB ASSY (SWING) |
| 102. | YX32W00002S102 | [1] | KOB BODY | |
| 201. | YX32W00002S201 | [1] | SHAFT | KOB |
| 202. | YX32W00002S202 | [1] | GEAR | KOB |
| 203. | YX32W00002S203 | [4] | GEAR | KOB |
| 204. | YX32W00002S204 | [1] | GEAR | KOB |
| 210. | YX32W00002S210 | [3] | GEAR | KOB |
| 211. | YX32W00002S211 | [1] | GEAR | KOB |
| 230. | YX32W00002S230 | [1] | CARRIER | KOB SPIDER |
| 231. | NSS | [1] | NOT SOLD SEPARAT | CON SPIDER |
| 282. | YX32W00002S282 | [4] | PIN | KOB |
| 283. | NSS | [3] | NOT SOLD SEPARAT | CON PIN |
| 285. | YX32W00002S285 | [7] | PLATE | KOB |
| 286. | YX32W00002S286 | [1] | WASHER | KOB |
| 287. | YX32W00002S287 | [3] | PLATE | KOB |
| 311. | YX32W00002S311 | [1] | DIPSTICK | KOB BAR, LEVEL |
| 312. | YX32W00002S312 | [1] | PIPE | KOB TUBE |
| 401. | YX32W00002S401 | [1] | ROLLER BEARING | KOB |
| 402. | YX32W00002S402 | [1] | ROLLER BEARING | KOB FOR F2&F3) |
| 403. | YX32W00002S403 | [3] | NEEDLE BEARING | KOB |
| 602. | ZS23C12100 | [10] | CAPSCREW,Hex Socket Head, M12 x 100mm | KOB SCREW M12x1.75x100mm |
| 801. | YX32W00002S801 | [1] | OIL SEAL | KOB |
| 902. | 2453U439S905 | [2] | PLUG | KOB (FOR F1 ONLY) |
| 910. | 2453U276S287 | [4] | PIN | KOB SPRING |
| 911. | 2441U398S820 | [3] | RING | KOB RETAINING Superseded by part number: ZR16X03000 |
| 912. | ZR16X02500 | [1] | RING | KOB Retaining -- ID 23.2 x OD 25 x Th 1.2mm |
| 913. | 2441U333S825 | [1] | SNAP RING | KOB RETAINING Superseded by part number: ZR16X06500 |
| 915. | YX32W00002S915 | [1] | SEAL | KOB Superseded by part number: EW32W00003S915 |
| 920. | YX32W00002S920 | [1] | ADAPTER | KOB |
| 921. | YX32W00002S921 | [1] | HOSE | KOB |
| 922. | YX32W00002S922 | [1] | PLUG | KOB |
| 925. | YX32W00002S925 | [1] | BREATHER | KOB NIPPLE,GREASE(FOR F2 ONLY) |
| 926. | YX32W00002S926 | [1] | LUBE NIPPLE | KOB GREASE(FOR F2 ONLY) |
| . . | YX32W00002R100 | [1] | REPAIR KIT | KOB CONSISTS OF ITEM 231X1, 283X3 |
Company Adavantages
ØStrong part number database.
If you can provide the right model and part number, we can supply the right product.
ØProfessional and experienced salesperson.
Our founder has been into this field for more than 7 years, with rich experiences.
ØStrict and complete company rules.
We will try our best to meet customer’s delivery time. Before delivery, we must verify the part number or pictures of products one by one, to make sure that customers can receive high-quality and right-quantity goods.
ØGood management system.
No matter how big or small order, as long as customers place the order, we will provide exporting service free for charge.
ØGood service attitude.
If the customer has any questions about the product, In our receiving and knowing the situation, we will help the customer to solve the problem in the first place.As long as customers’ requirements are reasonable, we will endeavour to make them satisfied.
| Company Information |
Exhibition:
Factory:
Good reputation:
FAQ
1.What is the warranty time of the products?
The warranty time is 3/6 months based on the item details; We don't provide warranty time for original and used products.
2.What is your delivery time?
Generally, we will arrange the goods within 24 hours after your payment; if not in stock, stocking time is 3-7 days.
3.What are your main products ?
We are specialized in spare parts for excavator hydraulic system, such as travel/swing motor, travel/swing gearbox/parts, hydraulic pump/parts,gear parts,etc.If you need other excavator parts, we also can supply as your requirements.
Other planetary gear
The travel and swing gearbox parts we deal with 1st carrier, 2nd carrier, 3rd carrier, sun gear, gear shaft, vertical shaft, housing, hub, washer, planetary gear, pin, gear ring, cover, etc.
